MSZ50H Injection Blow Molding Machine
/// Techhnical Features:
Special designed dual-cylinder clamping unit,mould open and close fast,idle cycle time fast,efficiency high.
Dual proportional hydraulic system,precision control,energy saving 25% more than vane pump drive.
Horizontal injection design,plasticating reliable and operation easy.
Single crossbeam style clamping system,easy for mould amounting
Generality high,same mould fitting as MSZ45 and MSZ40.
/// Optional:
Servo pump drive, 25%-45% energy saving is available.
In mold labeling solution, one stop procedure, save cost of labor and workshop, completely fitting and excellent appearance.
| No. of cavities | 2 | 4 | 6 | 7 | 8 | 9 | 10 | 12 | 13 |
| Neck Diameter（mm） | 45 | 40 | 35 | 35 | 30 | 25 | 25 | 20 | 10 |
| Body Diameter（mm） | 80 | 60 | 50 | 45 | 40 | 35 | 30 | 25 | 20 |
| Max. Height（mm） | 220 | 180 | 140 | 100 | 80 | 70 | 60 | 50 | 40 |
| Max. Volume（ml） | 1000 | 400 | 200 | 100 | 60 | 40 | 30 | 20 | 15 |
| Injection system | Unit | MSZ50H | |
| Screw Diameter | mm | 45 | 50 |
| Screw L/D | L/D | 23:1 | 23:1 |
| Injection weight(HDPE) | g | 241 | 298 |
| Max.screw speed | rpm | 10-235 | |
| Heating capacity | KW | 10 | |
| Clamping system | |||
| Clamping force of injection | KN | 500 | |
| Clamping force of blowing | KN | 89 | |
| Max.Platen size(L*W) | mm | 560×390 | |
| Min.Mold thickness(H) | mm | 240 | |
| Heating capacity of mould | KW | 3.6 | |
| Stripping system | |||
| Stripping stroke | mm | 270 | |
| Dry cycle | sec | 3.5 | |
| Driving system | |||
| Motor power | KW | 22 | |
| Hydraulic pressure | Mpa | 15 | |
| Product range | |||
| Suitable bottle range | ml | 5-800 | |
| Max.bottle height | mm | ≤200 | |
| Max.Dia.of bottle | mm | ≤100 | |
| Others | |||
| Min.Air pressure | Mpa | 1.0 | |
| Discharge rate of compressed air | M³/min | ≥0.7 | |
| Water flowage | M³/h | 4 | |
| Total rated power with mold heating | KW | 35.6 | |
| Dimension(L*W*H) | M | 4.11×1.44×2.5 | |
| Net weight | ton | 5.7 | |
